EM 96 51.80m Anchor Handling
General Particulars
| Project Name | EM 96 |
| Basic Function | Anchor Handling / Towing Tug |
| Classification | Bureau Veritas |
| Descriptive Note | Anchor Handling and Towing Job |
| Gross Tonnage | 1,039 ton |
| L.O.A | 51.80 Meters |
| L.B.P | 44.40 Meters |
| Breadth Mld | 15.00 Meters |
| Depth Mld | 6.50 Meters |
| Design Draft | 5.00 Meters |
| Max Draft | 5.70 Meters |
Towing & Anchor Handling
| Bollard Pull | 75~80 Ton |
| Hyd. Towing Winch Upper & Lower Drum Capacity | 1000M x 52m Dia. Wire (10 Layers) |
| Brake Holding | 225 Ton |
| Combined set Hyd. Shark Jaw / Towing Pin | Shark Jaw - Maximum line tension of 300MT Tow Pin - Maximum line tension of 200MT |
Tank Capacity
| Daily Fuel Oil | 550.0 m3 |
| Fresh Water | 90.0 m3 with RO Plant of 5 TPD |
| Cargo Fuel Oil | 350.0 m3 |
Propulsion System
| 2X Main Engine | Mitsubitshi S12U-MPTK, 1100RPM Diesel driven with ratio 4.48:1 |
| 2X Propellers | KAPLAN nozzle Type four blade fixed pitch |
| Steering System | 2X 4.0MT Independent |
| Bow Thruster Unit | Schottel, 7T Thrust, Diesel Engine Driven |
